This example of a designing a speaker box makes use of many of the calculators found onthis site. You should also review the Speaker Building Guidefor additional help.

For this example, I picked 3 ScanSpeak drivers for a 3-way speaker -the same 3 used on the Crossover Tutorial.This design is old and the characteristics of these drivers have since changed and/or been discontinued.These 3 drivers might be smaller than what is expected of a typical 3-way system.The mid is 4' and the woofer is 6.5' in size, but this system is still capable ofproducing deep frequencies at 35Hz. The drivers I chose(with specifications provided by the manufacturer) are:

We will first use the Sealed vs. Ported Speaker Box Calculator to determine if a sealed or a ported enclosure should be used.The Sealed vs. Ported calculator uses the formula below. If the EBP is less than 50, then a Sealed Enclosure is recommended. Above 90~100 and a Ported Enclosure is recommended. Between 50 & 90 either type would work.

Efficiency Bandwidth Product (EBP) = Free Air Resonance (Fs) / Driver Electrical 'Q' (Qes)

The tweeter in our example is already sealed and doesn't require an enclosure.The EBP of our midrange and woofer drivers are calculated as:

Mid EBP = 77 / .36 = 213

Woofer EBP = 30 / .26 = 115

Both values are well above 90 and call for Ported Enclosures. To keep this example interesting,I am going to ignore these results and use one sealed enclosure and one ported enclosure to show the differences between the two.

A sealed chamber will be used for the mid and a ported enclosure for the woofer.Calculating box volume for a sealed box requires Vas, Fs, & Qts. We will use the standard .707 value for Qtc for a smooth roll-off at the low end.Calculating box volume and port size for a ported enclosure requires Vas, Fs, Qts, and the cone diameter.

To calculate the speaker box volume, we will use the Speaker Box Designer.We must remember to change to metric units in this calculator - all ScanSpeak numbers are in mm & liters. The sealed box midrange driver gives us:

.03 cubic feet (0.77 liters) is an extremely small space for a speaker. Remember we should have been using a ported enclosure for this driver.The speaker itself is only 4' round. If we go with a minimum 4' x 4' box (the smallest the speaker will allow), then the box can only be about 3' deep -But I am of course ignoring the space taken up by the speaker itself and the internal bracing.Also, these are internal dimensions. The thickness of the wood will make the box larger.

ScanSpeak doesn't provide driver displacement information, so we will use the Driver Displacement Calculator.We will use the diagrams provided by ScanSpeak to enter numbers into our Displacement Calculator.

The Displacement Calculator is a best guess to the displacement of the speaker driver. It is not exact, but the more information you provide the better it will be.We will use 103mm as the cone diameter - not the 130mm diameter of the outer metal edge of the driver.Mounting depth is 45.5mm and magnet diameter is 90mm. Magnet height is not provided, so we measured a value of 30mm assuming this drawing is to scale.If we had the drivers in hand, then we could measure them to be sure. We also need to indicate that we will be flush mounting the driver and using 3/4' thick lumber in our enclosure.

Now we are ready to use theSpeaker Box Enclosure Volume Calculator to determine the outer dimensions of the speaker box.Also be sure to read the Help for the Speaker Box Calculator.

To use this calculator, we enter a speaker diameter of 4', the Box Volume (0.77 liters), Driver Displacement Volume (0.24 liters), Wood Thickness(3/4' - same as above), and indicate we will be using 3/4' battens. Now it is up to the user to adjust the width, height, and depthof the speaker box until the volume is .77 liters. The width and height of the box must be at least 4' to make room for the speaker itself.We are going to use 7' as the width here so that the same box width will also work for our 6.5' woofer.

The Speaker Box Volume Calculator also provides the size of each panel of the box.We will not use this information as we will be building a single enclosure for all 3 drivers.

Now for the woofer. When using the ported speaker box calculator, the driver size (Effective Cone Diameter - D)is only used to determine port width. Using the Speaker Box Calculator for the ported box for the woofer gives us:

Our calculator gives us a .48ft³ enclosure with a 2' wide circular x 4.26' long port.Note: The port is given in both standard and metric units. These numbers are not the same. 2' = 5.08cm, not 5 cm exactly.The port length is calculated twice. Once for a port exactly 2' in diameter, and one for a port exactly 5cm in diameter.The assumption is that you will be purchasing an off the shelf port that only comes in nominal sizes.
